Capacity:1-100t
Material :stainless steel
Rated Output(mV/V) :2.0±0.001
Nonlinearity :±0.1%FS
Hysteresis :±0.1%FS
Repeatability :±0.1%FS
Capacity |
1-100t |
Material |
stainless steel |
Rated Output(mV/V) |
2.0±0.001 |
Nonlinearity |
±0.1%FS |
Hysteresis |
±0.1%FS |
Repeatability |
±0.1%FS |
Creep(30 minutes) |
±0.05%FS |
Zero balance |
±1.00%FS |
Temperature effect on zero |
±0.05%F.S./10℃ |
Temperature effect on output |
±0.05%F.S./10℃ |
Input resistance(Ω)
|
780±20 |
Output resistance(Ω)
|
700±10 |
Insulation resistance
|
≥5000MΩ |
Excitation voltage |
5V-10V(DC) |
Compensated temperature range |
-10~+50℃ |
Operating temperature range |
-20~+60℃ |
Safe overload |
120%FS |
Breaking loading |
150%FS |
Cable |
Φ5X 6M Or customized by request |
Cable color code |
Input: red+ black- Output: green+ white- |
This load cell can be used for battery testing too.
