Capacity: 0.5-50t
Material: Alloy steel/stainless steel
Rated Output(mV/V): 2.0±0.005
Nonlinearity: ±0.03%FS
Hysteresis: ±0.03%FS
Repeatability: ±0.02%FS
Strong impact resistance and partial load resistance
not affected by the loading point and support edge
with good linearity, good interchangeability
fixed installation, easy installation
Can withstand tension and pressure
Wheel shape load cell ZH-WS1
| Capacity | 0.5-50t | Material | Alloy steel/stainless steel |
| Rated Output(mV/V) | 2.0±0.005 | Nonlinearity | ±0.03%FS |
| Hysteresis | ±0.03%FS | Repeatability | ±0.02%FS |
| Creep(30 minutes) | ±0.02%FS | Zero balance | ±1.00%FS |
| Temperature effect on zero | ±0.02%F.S./10℃ | Temperature effect on output | ±0.02%F.S./10℃ |
| Input resistance（Ω） | 385±15 | Output resistance（Ω） | 350± 3 |
| 765±15 | 700±5 | ||
| Insulation resistance | ≥5000MΩ | Excitation voltage | 5V-10V(DC) |
| Compensated temperature range | -10~+50℃ | Operating temperature range | -20~+60℃ |
| Safe overload | 120%FS | Breaking loading | 150%FS |
| Cable | Φ5.4（6） X 9M | Cable color code | Input: red+ black- |
| Or customized by request | Output: green+ white- |
